high voltage ac dc single output 220v to 100v 20w ac dc power supply

FOB Reference Price:Get Latest Price
US $1-20 / Pieces | 50 Piece/Pieces Welcome trial order for ac dc converter. (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Henlv
Model Number:
AC220SXXDC-20W
Output Power:
1 - 50W
Output Type:
Single
Size:
62*45*22mm
Weight:
101g
Input Voltage:
85-265VAC(90-360VDC)
Output Voltage:
Single output
Type:
AC-DC Converter
Output Frequency:
150KHZ
Output Current:
4A
Item name:
48v dc power supply
Source effect:
input voltage from low to high
MTBF:
2000000h
Temperature Coefficient:
≤±0.03%℃
Isolation voltage:
2000VAC 5mA, 1 min
Max shell temperature:
85℃
Relative temperature:
10%~90%
Shell:
flame-retardant metal aluminum shell / red copper shell
Response time:
load change for every 30%, change rate is 1A/us, response time is 1ms
Operating temperature:
Industrial grade: -25~+ 55℃ military grade:-40~+ 85℃
Supply Ability
Supply Ability:
200000 Piece/Pieces per Month Ningbo factory
Packaging & Delivery
Packaging Details
Carton package for ac dc converter 20W , special package for customer is available.
Port
Ningbo
Lead Time :
15 days after receive payment

high voltage ac dc single output 220v to 100v 20w ac dc power supply

Product Description



Power Converter AC220SXXDC-XW 62.jpg

Our main products:

DC DC power supply------0.1-600W

AC DC power supply------0.1-120W

PS: our company could manufacture any input and output power module for customers. If you have any special requirements please contact us

Description: Wide-voltage input: 85VDC-265VDC(90VDC-360VDC), any voltage input conversion of non-isolation voltage output, accuarcy of +/-0.5% or 1%



Output features:

Over current, overload(according to your request),  output short-circuit, over-temperature protection circuit, self-resumption

Ripple/NoiseL20MHz):50mVp-p Max

Switch frequency: 40-150KHz



Product features:

Source effect: input voltage(from low to high)

Mean time between failtures(MTBF): 2000000h

Temperature coefficient:<0.03% °C

Isolation voltage: 2000VAC 5ma 1 minute

Working temperature: industrial grade -25°C~+55°C,  military grade -40°C~+125°C

Shell: high inflaming retarding plastic, aluminium metallicum, copper metal shell package

Max shell temperature: 85°C

Relative temperature: 10%-90%



Application:

Widely used in instruments and meters, electronic scales, controlled device, IC card watt-hour meter, air-conditioned computer controller, automation equipment, portable rechargeable battery, etc.

AC220SXXDC-20W power converter.jpgAC220SXXDC-20W power converter 62.jpg



Application

Communication Remote control system, Wireless data terminal system, Exchange system, Communication Equipment, Military areas,Highway,Railway,Aviation,Ship,Audio,LED driver,Liquid crystal display,Intelligent instrument,Automatic control equipment,Electronic equipment,Medical equipment,Chargers,Portable computer,Electronic watt-hour meter,IC card read/writer device, Golf system, Gsm solution system,Electrical and other fields.

QC & Certificate


Packaging & Shipping


Our Services
  • Free sample requested is available.
  • 10 years experience of converter industry.
  • 2 Years Warranty.
  • Top 10 Chinese converter supplier.
  • Fast response for any question within 24 hours.
  • Full technical support before/after sales.
  • Customized products available (OEM, ODM).
  • UL, ISO9001,ISO14000,CE,ROHS,EMC,EN6060-1, SGS,IEC61373,IEC/EN 61000-4
  • 5 Branches in Ningbo,Shanghai,Beijing,Shenzhen,Chengdu
  • Professional R&D members, Strictly quality test and Experienced workers
