220v ac 5v power supply circuit ac dc power converter for car system

FOB Reference Price:Get Latest Price
US $7-8 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Henlv
Model Number:
AC220S05DC-3W
Output Power:
1 - 50W
Output Type:
Single
Size:
37*22.9*14.9MM
Weight:
23G
Input Voltage:
85-265VAC, 90-360VDC
Output Voltage:
5V DC
Type:
DC/AC Inverters
Output Frequency:
50KHz-800KHz
Output Current:
600mA
color:
black
weight:
23g
load current:
600mA
Power:
3W
Supply Ability
Supply Ability:
20000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
bubble+color box+carton or as your request
Port
shanghai/shenzhen/ningbo
Lead Time :
5-7days

220v ac 5v power supply circuit ac dc power converter for car system

Product Description

AC220SXXDC-XW 37.jpg

Output characteristic:

The built-in EMI filtering unit, has an over-current, overvoltage ( according to your requirements ) and output short circuit.
Overload, overheating, protection circuit ( eliminating short circuit, overload, overload automatically eliminate)
Ripple / noise ( 20MHZ ): 50mVp-p max., 40KHZ-150KHZ switching frequency



General characteristic:

Source effect: the input voltage from the low to high, the insulation resistance of 10000000000 Ω
Mean time between failure ( MTBF ) 2000000h
Temperature coefficient is ≤ ± 0.03% ℃, hold time: 20ms (full load of typical value)
Isolation voltage: 2000VAC 5mA, 1min.
Operating temperature: industrial grade: -25 ~ +55 ℃, military grade-40~+85℃,
Storage temperature: -40℃ ~ +125 ℃
Response time: load change for every 30%, the rate of change of 1A/us, response time is 1ms
Shell: high flame retardant, metal aluminum shell / purple copper package
Max shell temperature : 85 ℃, relative temperature; 10%~90%


Application

Communication Remote control system, Wireless data terminal system, Exchange system, Communication Equipment, Military areas,Highway,Railway,Aviation,Ship,Audio,LED driver,Liquid crystal display,Intelligent instrument,Automatic control equipment,Electronic equipment,Medical equipment,Chargers,Portable computer,Electronic watt-hour meter,IC card read/writer device, Golf system, Gsm solution system,Electrical and other fields.





QC & Certificate

 testenterprise qualification

Packaging & Shipping


Our Services



  • Free sample requested is available.
  • 10 years experience of converter industry
  • Two Years Warranty
  • Top 10 Chinese converter supplier
  • Fast response for any question within 24 hours.
  • Full technical support before/after sales.
  • Customized products available (OEM, ODM).
  • ISO9001,ISO14000,CE,UL,ROHS,EMC,EN6060-1, SGS,IEC61373,IEC/EN 61000-4
  • 5 Branches in Ningbo,Shanghai,Beijing,Shenzhen,Chengdu
  • Professional R&D members, Strictly quality test and Experienced workers
