25mm height single output 220v ac 5v dc converter 30w ac dc power converter

FOB Reference Price:Get Latest Price
US $1-150 / Pieces | 5 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
HenLv
Model Number:
AC220S(D)xxDC-xW
Output Power:
1 - 50W
Output Type:
Dual
Size:
72X50X25mm
Weight:
37+-0.5g
Input Voltage:
85-265VAC(90-360VDC)
Output Voltage:
5-48V,+-5~+-24v
Type:
DC/AC Inverters
Output Frequency:
40-150KHz
Output Current:
833-6000mA, +-833~+-4000mA
Color:
black
name:
ac dc converter
Certificate:
CE ROHS
Warranty:
2 Years
Protection:
Short Circuit Protection
Efficiency:
85%
Supply Ability
Supply Ability:
200000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
carton box
Port
Ningbo

25mm height single output 220v ac 5v dc converter 30w ac dc power converter


Output characteristics: General characteristic:




The built-in EMI filtering unit, has an over-current, overvoltageSource effect: the input voltage from the low to high, the insulation resistance of 10000000000 Ω
( according to your requirements ) and output short circuit. Mean time between failure ( MTBF ) 2000000h Overload, overheating, protection circuit ( eliminating short Temperature coefficient is ≤ ± 0.03% °C, hold time: 20ms (full load of typical value) circuit, overload, overload automatically eliminate) Isolation voltage: 2000VAC 5mA, 1min.
Ripple / noise ( 20MHZ ): 50mVp-p max., 40KHZ-150KHZ Operating temperature: industrial grade: -25 ~ +55 °C, military grade-40~+85°C,
switching frequency Storage temperature: -40°C ~ +125 °C Response time: load change for every 30%, the rate of change of 1A/us, response time is 1ms Shell: high flame retardant, metal aluminum shell / purple copper package
Max shell temperature : 85 °C, relative temperature; 10%~90%



72 size product type and pin diagram



single/Dual Common output type

AC220S(D)XXDC-xW product type,can achieve power: 30W 40WMax

(Customers can request custom talor-made products for different pins and related parameters)
